Lubricating barrel special labeling machine

AK-V131LB Lubricant Barrel Labeling Machine is an automatic self-adhesive labeling for plastic/iron barrels for lubricants/greases. It can realize the circumference of barrels such as 1L/2L/5L/15L/16L/18L/20L. Labeling and fixed-point positioning labeling can be used with automatic production lines or stand-alone. It is an essential equipment for the petrochemical industry.

Performance parameters:

· Feeder type: imported feeder

· Labeling speed: 5-50 barrels / minute

· Label size: width 10-200mm, minimum length 10mm

· Labeling accuracy: ±3 mm (without applicator and label error)

· Marking speed: 3~50 m/min

· Host direction: from left to right or from right to left

· Power supply: 220V±5% 50/60Hz

· Air source: 0.4~0.7MPa

Equipment characteristics:

1. The positioning device adopts the driving wheel driven by the motor and the two driven wheels pushed by the cylinder. The inclination of the three wheels can be adjusted with the inclination of the barrel wall, so that the wheel fits close to the barrel wall to ensure reliable and flat labeling. Avoid wrinkles.

2. The driving roller made of gold steel sand material has excellent friction and ensures that the label movement process does not slip.

3. The whole electronic control system is controlled by PLC, adopts imported touch screen, which is convenient and intuitive to operate, and contains rich help functions and fault display functions.

4. The main components are all imported products.

5. With memory storage function, it can store 50 sets of parameters and can name different programs. To change different specifications or use different production capacities, you only need to adjust different parameters without having to adjust again, which greatly improves work efficiency.
