产品介绍
The carton diagonal sealing labeling machine AK-V214T is mainly used for the diagonal sealing labeling of various flat or square cartons and other objects in the medical, food, daily chemical, anti-counterfeiting and other industries.
Technical Parameters:
· Feeder type: COLLAMAT 6600
· Labeling speed: 150~200 pieces/min (related to the size of the sticker and the label)
· Labeling accuracy: ±1.0mm (excluding package and label errors)
· Marking speed: 3~30m/min
· The size of the object to be attached: length 90~200mm, height 10~100mm
· Dimensions: L2300×W980×H1300 (mm)
· Power supply: 220V±5% 50/60Hz
· Working pressure: 0.4~0.6MPa
Performance characteristics:
· The most important part of the labeling machine is the feeder. We compare the feeder to the heart of the labeling machine. The labeling device of the labeling machine provided by our company is made by Coollamat of Switzerland.
· The whole machine can be equipped with a transparent protective cover and a safety interlock switch to ensure the safety of operators.
· The whole electronic control system is controlled by PLC and operated by touch screen. It is easy to operate and intuitive. It has rich help function and fault display function.
· Both the feeder and the pneumatic aids are more flexible and can be used to seal the opposite sides of the object.
· Double diagonal labeling has a detection mechanism that can be automatically rejected if it is not labeled.
· It has a special top belt mechanism to ensure that the label is better in the case of stable and controlled labeling.
